Home > Gasoline Generator (Open Type)
SPECEFICATIONS:
Model No.
UT2500(E)-A
UT3000(E)-A
UT5500(E)-A
UT6500(E)-A
UT7500(E)-A
Engine Model
H170F(E)
H170F(E)
H188F(E)
H190F(E)
H192F(E)
Displacement
212 ml
212 ml
389 ml
420 ml
438 ml
Starting Mode
Manual Start / Electric Start
Manual Start / Electric Start
Rated Power
2.0 KW
2.5 KW
5.0 KW
6.0 KW
7.0 KW
Max. Power
2.2 KW
2.8 KW
5.5 KW
6.5 KW
7.5 KW
Rated Voltage
220 V
220 V
220 V
220 V
220 V
Rated Frequency
50 Hz
50 Hz
50 Hz
50 Hz
50 Hz
Fuel Tank Capacity (L)
15 L
15 L
25 L
25 L
25 L
Continuous Working Time
10 Hours
9 Hours
9 Hours
8 Hours
8 Hours
Product Dimension (mm)
590 x 430 x 440
590 x 430 x 440
680 x 510 x 540
680 x 510 x 540
680 x 510 x 540
Carton Size
605 x 460 x 465
605 x 460 x 465
700 x 540 x 580
700 x 540 x 580
700 x 540 x 580
Net/Gross Weight (Manual)
41 / 43Kgs
41 / 43Kgs
83 / 87Kgs
83 / 87Kgs
83 / 87Kgs
Net/Gross Weight (Electricl)
45 / 47Kgs
45 / 47Kgs
87 / 89Kgs
87 / 89Kgs
87 / 89Kgs
20GP/40GP/40HQ Loading
188 / 384 / 480
188 / 384 / 480
128 / 256 / 256
128 / 256 / 256
128 / 256 / 256
PRODUCT OPTIONS:
Socket Type Option: Euro type, American type, Australian type and oversea civil use and industrial use.
ADCANTAGES OF TECHNOLOGY:
1.
Appearance Color Changeable
2.
3.
Frequency choices 50HZ/60HZ
4.
Voltage choices :110/150/120/220/230/240V
5.
With optional wheels and handle choices
6.
With optional choices: handle start and electric start
7.
Can be with 12V DC charger
8.
With optional battery tray choices: internal and external.
| No. | Photo | Parts/Assembly | the Details of Advantages of Technology |
| 1 |
 |
Cylinder Head Combination |
optimized design for the exhaust port and improved the gasoline engine combustion efficiency |
| 2 |
 |
Cylinder Head Cover Combination |
New design structure, fuel and air can be se separated completely |
| 3 |
 |
Crankshaft | Increased the fillet hardening process, more durable |
| 4 |
 |
Valve Mechanism | Optimized valve mechanism and high reliability |
| 5 |
 |
Fly Wheel | Optimized cooling apperance. |
